| APPLICATIONS |
각종 필름 코팅용 제품 |
| Model No. |
IM-PM01-003M |
| Light Source |
Mercury UV Lamp &Metal Halide UV |
| Power Supply |
AC 1Φ,3Φ/220,380V / 50,60㎐ / |
| Cooling System |
공냉식 |
| Curing Width |
120mm 극간150mm |
| Reflector |
Cold Mirror + Hot Mirror |
| Dimension( W x D x H ) |
177 * 500 * 278 |
| Option |
N2 + 기타 |
|
|
 |
 |
| APPLICATIONS |
각종 웨이퍼 및 소형 제품의경화에 적합 |
| Model No. |
IM-PM01-005M |
| Light Source |
Mercury UV Lamp &Metal Halide UV |
| Power Supply |
AC 3Φ/220,380V / 50,60㎐ / |
| Cooling System |
공냉식 |
| Curing Width |
340mm 극간400mm |
| Reflector |
Cold Mirror + Hot Mirror |
| Dimension( W x D x H ) |
177 * 663 * 258 |
| Option |
N2 + 기타 |
|
|
|
 |
| APPLICATIONS |
포터블 경화기 접착,코팅,인쇄용 제품 |
| Model No. |
IM-PM01-002M |
| Light Source |
Mercury UV Lamp &Metal Halide UV |
| Power Supply |
AC 1Φ,3Φ/220,380V / 50,60㎐ / |
| Cooling System |
공냉식 |
| Curing Width |
160mm 극간200mm |
| Reflector |
AL반사판 |
| Dimension( W x D x H ) |
180 * 565 * 190 |
| Option |
Hot/Cold Mirror,무단제어,N2+기타 |
|
|
|
|
|
